Camera |
Image Sensor |
1/3” 4-Megapixel Progressive Scan CMOS Sensor |
Minimum Illumination |
0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories) |
Shutter Speed |
Self-adaptive shutter |
Lens |
4mm @ F1.6 Viewing angle: 100°(Diagonal), 83°(Horizontal), 44°(Vertical) |
PT Angle |
Pan: 340°, Tilt: 65° |
Day & Night |
IR-Cut filter with auto-switching |
DNR |
3D DNR |
Night Vision |
Up to 49 ft / 15 m |
Video & Audio |
Max. Resolution |
2560 × 1440 |
Frame Rate |
15fps. Self-Adaptive during Network Transmission |
Video Compression |
H.265 / H.264 |
Video Bit Rate |
Quad HD; HD; Standard. Adaptive Bit Rate. |
Audio Bit Rate |
Self-Adaptive |
Max. Bitrate |
2 Mbps |
Network |
Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20 MHz |
Security |
64 /128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Transmission Rate |
11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
Wi-Fi Pairing |
AP pairing |
Protocol |
EZVIZ cloud proprietary protocol |
Interface Protocol |
EZVIZ cloud proprietary protocol |
Minimum Network Requirement |
4Mbps |
Function |
Detection |
Smart Human Motion Detection |
Two-way Talk |
Supports |
General Function |
Anti-Flicker, Heart Beat, Password Protection, Watermark |
Storage |
Local Storage |
Build-In 32GB eMMC Storage |
Cloud Storage |
Supports EZVIZ CloudPlay storage (Subscription required) |
General |
Operating Conditions |
-20 °C to 50 °C (-4 °F to 122 °F ), humidity 95% or less (Non-condensing) |
IP Grade |
Weatherproof Design |
Power Consumption |
Max. 10W |
Product Dimensions |
183 × 116 × 166 mm (7.20 × 4.57 × 6.52 inch) |
Packaging Dimensions |
216 × 145 × 203 mm (8.50 × 5.71 × 7.99 inch) |
Weight |
Net: 803 g (28.32 oz) With package: 1060 g (37.39 oz) |
Battery |
Battery Capacity |
10400 mAh |
Power Supply |
DC 5V / 2A |
