General |
Dimensions |
75.5 × 75.5 × 155 mm (2.97 × 2.97 × 6.10 inch) |
Package Dimensions |
227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch) |
Weight |
Net weight: 438 g (15.45 oz) With package: 676 g (23.84 oz) |
IP Grade |
IP67 |
Operating Conditions |
-30 °C ~ 60 ºC (-22 °F ~ 140 °F ) Humidity 95% or less (non-condensing) |
Camera |
Image Sensor |
1/2.7”Progressive Scan CMOS |
Shutter Speed |
Self-adaptive shutter |
Lens |
2.8mm @ F2.0, viewing angle: 122° (Diagonal), 106° (Horizontal), 56° (Vertical) 4mm @ F2.0, viewing angle:102° (Diagonal), 86° (Horizontal), 44° (Vertical) |
Minimum Illumination |
0.01 lux @ (F2.0, AGC ON), 0 Lux with IR |
Lens Mount |
M12 |
Day / Night Switch |
IR-Cut filter with auto-switching |
DNR |
3D DNR |
WDR |
Digital WDR |
BLC |
Supports |
IR Night Vision Distance |
Up to 98 ft / 30 m |
Video & Audio |
Max. Resolution |
2304 × 1296 pixels |
Frame Rate |
Max: 30fps; Self-Adaptive during network transmission |
Video Compression |
H.265 / H.264 |
Video Bit Rate |
Quad HD; Full HD; HD; Standard. Adaptive bit rate. |
Audio Bit Rate |
Self-Adaptive |
Max. Bitrate |
3 Mbps |
Network |
Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20 MHz |
Security |
64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
Wi-Fi Pairing |
AP Pairing |
Protocol |
EZVIZ Cloud Proprietary Protocol |
Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
