Prolongateur de portée Wi-Fi RE305 AC1200

Type de prise

EU, UK, US

Standards et Protocoles

IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b

Interface

1 * 10/100M Ethernet Port (RJ45)

Bouton

WPS Button, Reset Button

Consommation

7.3W（max power consumption）

Dimensions (LxPxH)

3.1*3.0*3.0 in. (80*78*77mm)

Antenne

2* external

Fréquence

2.4GHz & 5GHz(11ac)

Débit du signal

5GHz:Up to 867Mbps
2.4GHz:Up to 300Mpbs

Sensibilité de réception

5GHz：
11a 6Mbps:-91dBm@10% PER
11a 54Mbps: -74dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -63dBm@10% PER
11ac HT80 mcs9: -59dBm@10% PER
2.4GHz
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER

Modes WiFi

Range Extender/Access Point
Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band

Fonctions WiFi

Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band
Access Control
LED Control
Domain Login Function

Sécurité WiFi

64/128-bit WEP
WPA-PSK / WPA2-PSK

Puissance de transmission

<17dBm(2.4GHz)
<17dBm(5GHz)

Certification

CE, FCC, RoHS

Contenu de l'emballage

AC1200 Wi-Fi Range Extender RE305
Quick Installation Guide

Dimensions de l'emballage (LxPxH)

6.15*4*3.7in. (156.5*101.5*95mm)

Système requis

Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.

Environnement

Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
