Camera |
Image Sensor |
1/2.7" Progressive Scan CMOS |
Shutter Speed |
Self-adaptive shutter |
Lens |
4mm @ F1.6, view angle: 87° (Horizontal), 105° (Diagonal) 6mm @ F1.6, view angle:55° (Horizontal), 66° (Diagonal) |
PT Angle |
Pan: 352°, Tilt: 95° |
Minimum Illumination |
0.5 Lux @(F1.6, AGC ON), 0 Lux with IR |
Lens Mount |
M12 |
Day & Night |
IR-cut filter with auto-switching |
DNR |
3D DNR |
WDR |
Digital WDR |
BLC |
Supports |
Black & White Night |
30 m / 100 ft. |
Video & Audio |
Max. Resolution |
1920 × 1080 |
Frame Rate |
Max:30 fps; Self-Adaptive during network transmission |
Video Compression |
H.265 / H.264 |
Video Bit Rate |
Full HD; Hi-Def; Standard. Adaptive bit rate. |
Audio Bit Rate |
Self-Adaptive |
Max. Bitrate |
2 Mbps |
Network |
Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20 MHz |
Security |
64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate |
11b: 11Mbps, 11g : 54Mbps, 11n: 72Mbps |
Wi-Fi Pairing |
AP pairing |
Protocol |
EZVIZ cloud proprietary protocol |
Interface Protocol |
EZVIZ cloud proprietary protocol |
Wired Network |
RJ45 × 1 (10 M / 100 M Adaptive Ethernet Port) |
Storage |
Local Storage |
MicroSD card slot (Max. 256G) |
Cloud Storage |
EZVIZ Cloud Storage |
Function |
Smart Alarm |
AI Person Detection |
Customized Alert Area |
Supports |
Audio |
Supports mic |
General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
General |
Operating Conditions |
-30°C ~ 60°C (14°F to 113 °F), Humidity 95% or less (non-condensing) |
IP Grade |
IP65 |
Power Supply |
DC 12V / 1A |
Power Consumption |
MAX. 6W |
Dimensions |
158 x 157 x 149 mm (6.22 x 6.18 x 5.87 inch) |
Packaging Dimensions |
197 x 185 x 205 mm (7.76 x 7.28 x 8.07 inch) |
Weight |
885 g (31.22 oz) |
Net Weight |
510 g (17.99 oz) |
